Product Dimensions 12"h x 46.375"w x 22.50"d
The extra size and blower capacity of the BHPSLD model can be used above professional-style cooking equipment. Click on the models for a list of our base model numbers for standard sizes; simply select the model you need, and then specify the finish (painted or stainless steel). All liners in this series are 22 1/2" deep. Recommended mounting height is 27" - 30" above the cooking surface. All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.Read More
CALL FOR AVAILABILITY
The standard ventilation of the BHPSLD model is intended for use over standard cooking equipment. All liners in this series are 22 1/2" deep. Recommended mounting height is 27" - 30" above the cooking surface. All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit. Special Notes: LED lights. This model is not available with heat lamps.
Sones: 6.3
Number of Lights : 3
CFM: 900
General Specs | |
| Width (in.) | 46.375 |
| Height (in.) | 12 |
| Duct Size (in.) | 10 |
| Depth (in.) | 22.50 |
| Collection | Premier Magic Lung® |
| Color | Gray |
| Appliance Fit Width (cm.) | 118 |
| Color Finish Name | Gunsmoke |
| Range Hood Type | Under Cabinet |
| ENERGY STAR Certified | No |
| Appliance Fit Width (in.) | 47 |
| Maximum CFM | 900 |
| Bulb Type | LED |
| Sones Rating | 6.3 |
| Height Above Cooktop | 27 - 30 |
| Width (cm) | 117.79 |
| Height (cm.) | 30.48 |
| Depth (cm.) | 57.15 |
| Height Above Cooktop Centimeter | 68.58 - 76.20 |
| Voltage | 115 |
| Noise Level (Sones) | Standard - (High) |
| Ventilation Type | Ducted |
More Information | |
| RPM | 1550 |
| CFM SP@0.0" | 1350 |
| Equiv. CFM$ | 900 |
| CFM SP@0.1" | 804 |
| CFM SP@0.2" | 725 |
| CFM SP@0.3" | 655 |
