Product Dimensions 12"h x 28.375"w x 19.25"d
The standard ventilation of the BHSLD model is intended for use over standard cooking equipment. Click on the models for a list of our base model numbers for standard sizes; simply select the model you need, and then specify the finish (painted or stainless steel). All liners in this series are 19 1/4" deep. Recommended mounting height is 24" - 27" above the cooking surface. All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.Read More
CALL FOR AVAILABILITY
The standard ventilation of the BHSLD model is intended for use over standard cooking equipment. Click on the models for a list of our base model numbers for standard sizes; simply select the model you need, and then specify the finish (painted or stainless steel). All liners in this series are 19 1/4" deep. Recommended mounting height is 24" - 27" above the cooking surface. All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.
Sones: 5.4
Number of Lights : 2
CFM: 300
General Specs | |
| Width (in.) | 28.375 |
| Height (in.) | 12 |
| Duct Size (in.) | 6 |
| Depth (in.) | 19.25 |
| Collection | Premier Magic Lung® |
| Color | Stainless Steel |
| Appliance Fit Width (cm.) | 72 |
| Color Finish Name | Stainless Steel |
| Range Hood Type | Insert |
| ENERGY STAR Certified | No |
| Appliance Fit Width (in.) | 29 |
| Maximum CFM | 300 |
| Bulb Type | LED |
| Sones Rating | 5.4 |
| Height Above Cooktop | 24 - 27 |
| Width (cm) | 72.07 |
| Height (cm.) | 30.48 |
| Depth (cm.) | 48.9 |
| Height Above Cooktop Centimeter | 60.96 - 68.58 |
| Voltage | 115 |
| Noise Level (Sones) | Standard - (High) |
| Ventilation Type | Ducted |
More Information | |
| RPM | 1550 |
| CFM SP@0.0" | 300 |
| Equiv. CFM$ | 450 |
| CFM SP@0.1" | 273 |
| CFM SP@0.2" | 245 |
| CFM SP@0.3" | 225 |
