Gaggenau 200 Series 36" Wall Hood-Stainless Steel-AW230790

Model #: AW230790
546588
Gaggenau
At a Glance

Gaggenau 200 Series 36" Wall Hood-Stainless Steel with LED light and 3 power level

$3,549.00Save $150.00
$3,399.00
Don't Forget These Add Ons

4 Year Protection Plan

$384.99

x 1

Haul Away Service

$30.00

x 1


Get to know this product.

With its stepped design, this wall-mounted hood blends harmoniously into the kitchen environment and impresses with its technology. The energy-saving fan and effective rim extraction filter ensure excellent air quality in the kitchen.

Main Facts

  • Classic Gaggenau design
  • Highly efficient extraction of cooking vapors
  • Low-noise blower
  • Patented filter technology with high level of grease absorption
  • Rim extraction filter with flat and easy-to-clean stainless steel surface
  • Dimmable LED light for optimum illumination of the entire cooktop
  • Air extraction or recirculation system
  • Air recirculation module with activated charcoal filters: quiet and highly efficient air recirculation solution with odor reduction as in air extraction mode, and long replacement intervals

Output

  • Air extraction: 622 / 765 m³/h.
  • Air recirculation: 510 / 571 m³/h.
  • Odor reduction recirculation 95%.

Features

  • Three electronically controlled power levels and an intensive mode.
  • Grease filter saturation indication by flashing light
  • Patented rim extraction filter, dishwasher-safe.
  • Warm white LED light (3600 K), continuously dimmable.
  • Airflow-optimized interior for efficient air circulation.
  • Easy mounting system for simple installation and alignment.
  • The package includes an one-way flap.

Rating

  • Total rating: 425 W.
  • Total Amps: 3 A.
  • 110 - 127 V / 60 Hz
  • Connecting cable 1.3 m with plug.
Specifications

Dimensions

Shipping Weight:68
Min Chimney Height:22.94

Display

Controls:Digital

General Features

Filter Type:Patented Rim Extraction
Cleanability:Dishwasher Safe

Other

Watts:425
Number of Lights:3

Misc. Specs

Width (in.)35.44
Height (in.)37.56
Duct Size (in.)6
Appliance ColorStainless Steel
Color Finish NameStainless Steel
Range Hood TypeWall Mounted
ENERGY STAR QualifiedNo
Product Weight57
Appliance Fit Width (in.)36
Height (cm)95.4
Width (cm)90.02
Product Weight (kg)25.85
Amp3
Voltage110/127
Frequency60
